The table outlines the sections' Parameters including Definition:
PARAMETER
DEFINITION
PU
By s electing P U ( Per Unit) w ill
present the v alues as p art o f
nominal (for example: 230V 100.0%)
VRMS
= Number of Samples
= Specific Channel
10/12 Continuous Non-Overlapping Cycles
In Accordance with IEC61000-4-30
ARMS
= Number of Samples
= Specific Channel
10/12 Continuous Non-Overlapping Cycles
In Accordance with IEC61000-4-30
Min Value
Minimum R MS v alue s ince t he initial p ower u p or t he m ost
recent selection of:
Max
Value
Maximum R MS v alue since t he i nitial p ower u p o r the m ost
recent selection of:
THD
C = Harmonic RMS Value
n = Harmonic Order
