: Decimal value of binary states 10.01 to
10.14
Adjustment range :0 to 16383
This parameter is used with a serial communications
interface. The value of this parameter is the addition of the
drive bits envisaged for read-only mode, with the following
binary weights:
- 10.01 = 2
0
- 10.02 = 2
1
- 10.03 = 2
2
- 10.04 = 2
3
- 10.05 = 2
4
- 10.06 = 2
5
- 10.07 = 2
6
- 10.08 = 2
7
- 10.09 = 2
8
- 10.10 = 2
9
- 10.11 = 2
10
- 10.12 = 2
11
- 10.13 = 2
12
- 10.14 = 2
13
to : Not used
:V
min
alarm
Adjustment range :0 or 1
0 (Disabled) (OFF)
1 (Enabled) (On)
Changes to 1 when the motor speed (5.04) < V
min
(1.07 or
21.02) + 3.51 in open loop mode or speed (3.02) < V
min
(1.07 or 21.02) + 3.51 in closed loop mode.
10.51 changes back to 0 when the speed is greater than
(5.04) < V
min
(1.07 or 21.02) + 3.51 + 10 rpm in open loop
mode or greater than (3.02) < V
min
(1.07 or 21.02) + 3.51
+ 10 rpm.
Note: In bipolar mode, alarm 10.51 is not active.
:V
max
alarm
Adjustment range :0 or 1
0 (Disabled) (OFF)
1 (Enabled) (On)
Changes to 1 when the motor speed (5.04) > V
max
(1.06 or
21.01) - 3.52 in open loop mode or speed (3.02) > V
max
(1.06 or 21.01) - 3.52 in closed loop mode.
10.52 changes back to 0 when the speed is lower than
(5.04) > V
max
(1.06 or 21.01) - 3.52 - 10 rpm in open loop
mode, or (3.02) > V
max
(1.06 or 21.01) - 3.52 - 10 rpm.
: Maximum speed
Adjustment range :0 or 1
0 (Disabled) (OFF)
1 (Enabled) (On)
Changes to 1 when the motor speed (5.04) > V
max
(1.06 or
21.01) - 15 rpm.
10.53 changes back to 0 when the speed is lower than
(5.04) > V
max
(1.06 or 21.01) - 3.53 - 25 rpm.
to : User alarms 1 to 4
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (OFF)
1 (Enabled) (On)
When these parameters change to 1, the drive display
alternates between the messages "Alar. " and "USr(1to4)" (no
tripping of the drive).
Note:
User alarm 1 overrides user alarm 2.
User alarm 2 overrides user alarm 3.
User alarm 3 overrides user alarm 4.
to : Not used
: User trip 1
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (OFF): The drive has not tripped.
1 (Enabled) (On): The drive trips, may or may not control
deceleration according to the configuration of 10.62 and
generates a trip code tr01.
Note: Automatic reset (10.34) is not permitted.
: Not used
: User trip 2
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (OFF): The drive has not tripped.
1 (Enabled) (On): The drive trips, may or may not control
deceleration according to the configuration of 10.64 and
generates a trip code tr02.
Note: Automatic reset (10.34) is not permitted.
: Not used
: User trip 3
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (OFF): The drive has not tripped.
1 (Enabled) (On): The drive trips, may or may not control
deceleration according to the configuration of 10.66 and
generates a trip code tr03.
