96
ADVANCED USER GUIDE
Commander SX
IP66/Nema 4X variable speed drive
MENU 10: DRIVE STATES AND DIAGNOSTICS
CONTROL TECHNIQUES
3854 en - 03.2008 / b
: Not used
: User trip 4
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (OFF): The drive has not tripped.
1 (Enabled) (On): The drive trips, may or may not control
deceleration according to the configuration of 10.68 and
generates a trip code tr04.
: Not used
: Trip active at standstill
Adjustment range :0 or 1
Factory setting :1
0 (Disabled) (OFF):
1 (Enabled) (On):
This parameter is used to make drive trips active at standstill.
The trips concerned are: UU, phAC , EnC1, EnC2, EnC3,
Oht2, itAC, th, CL1, CL2, CL3, Oht1.
: Trip auto-reset when
powered
Adjustment range :0 or 1
Factory setting :1
0 (Disabled) (OFF):
1 (Enabled) (On):
This parameter is used to automatically reset the trip with
power "UU" applied.
to : Not used
: LED command
Adjustment range :0 to 1000
In the PUMP preset configuration (11.46 = 8), this parameter
is used to control output ADI03:
- 10.90 is at 0 when 10.01 is at 1 (drive healthy).
- 10.90 is at 1000 when 10.01 is at 0 (drive tripped).
- 10.90 changes alternately from 600 to 1000 when 10.09
is at 1 (current limiting active).
: Increase number of
automatic trips
Adjustment range :0 or 1
Factory setting :0
0 (Disabled) (ON)
1 (Enabled) (OFF)
This parameter is used to obtain more automatic trip resets.
When it is enabled, the maximum value of 10.34 changes
from 5 to 100.
In addition, the 10-second delay before detection of IGBT
overcurrent (OIAC) is no longer taken into account (see
10.33). The delay is then set by 10.35.
10.66
10.67
10.68
10.69
10.70
10.71 10.89
10.90
10.91
