Page #314 background imageLoading...
Page #314 background image
Menus 15 to 17
SM-I/O 120V
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
314 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
This parameter shows the version of software programmed into the Solutions Module. The software sub version is displayed in Pr x.51.
These two parameters display the software version in the form of:
Pr x.02 = xx.yy
Pr x.51 = zz
This word is used to determine the status of the digital inputs and relays by reading one parameter. The bits in this word reflect the state of Pr x.03 to
Pr x.10.
x.02
Solutions Module software version
RO Uni NC PT
Ú
00.00 to 99.99
Ö
Update rate: Write on power-up
x.03
T4 digital input 3 state
x.04
T5 digital input 4 state
x.05
T7 digital input 5 state
x.06
T8 digital input 6 state
x.07
Relay 1 state
x.08
Relay 2 state
x.09
T1 digital input 1 state
x.10
T2 digital input 2 state
RO Bit NC PT
Ú
OFF (0) or On (1)
Ö
Update rate: Background write
x.11
T1 digital input 1 invert
x.12
T2 digital input 2 invert
x.13
T4 digital input 3 invert
x.14
T5 digital input 4 invert
x.15
T7 digital input 5 invert
x.16
T8 digital input 6 invert
x.17
Relay 1 invert
x.18
Relay 2 invert
RW Bit US
Ú
OFF (0) or On (1)
Ö
OFF (0)
Update rate: Background read
x.20
Digital inputs/ relay outputs read word
RO Uni NC PT
Ú
0 to 255
Ö
Update rate: Background write
Bit Digital input/ relays
0 Digital input 1
1 Digital input 2
2 Digital input 3
3 Digital input 4
4 Digital input 5
5 Digital input 6
6 Relay 1
7 Relay 2
