Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menus 15 to 17
SM-I/O 120V
Unidrive SP Advanced User Guide 315
Issue Number: 10 www.controltechniques.com
The error status is provided so that only one option error trip is required for each Solutions Module slot. If an error occurs, the reason for the error is
written to this parameter and the drive may produce a SLx.Er trip, where x is the slot number. A value of zero indicates that the Solutions Module has
not detected an error, a non-zero value indicates that an error has been detected. (See Table 5-25 on page 312 for the meaning of the values in this
parameter). When the drive is reset, this parameter is cleared for the relevant Solutions Module.
This Solutions Module includes a temperature monitoring circuit. If the PCB temperature exceeds 90°C, the drive fan is forced to operate at full speed
for a minimum of 10s on Unidrive SP. If the temperature falls below 90°C, the fan can operate normally again. If the PCB temperature exceeds 100°C,
the drive is tripped and the error status is set to 74.
The Solutions Module includes a processor with software. The software version is displayed in Pr x.02 and Pr x.51 in the form Pr x.02 = xx.yy and
Pr x.51 = zz.
Where:
xx specifies a change that affects hardware compatibility
yy specifies a change that affects product documentation
zz specifies a change that does not affect the product documentation
When a Solutions Module is installed that does not contain software, both Pr x.02 and Pr x.51 appear as zero.
x.21
T1 digital input 1 destination
x.22
T2 digital input 2 destination
x.23
T4 digital input 3 destination
x.24
T5 digital input 4 destination
x.25
T7 digital input 5 destination
x.26
T8 digital input 6 destination
RW Uni DE US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on drive reset
x.27
Relay 1 source
x.28
Relay 2 source
RW Uni US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on drive reset
x.50
Solutions Module error status
RO Uni NC PT
Ú
0 to 255
Ö
Update rate: Background read
x.51
Solutions Module software sub-version
RO Uni NC PT
Ú
0 to 99
Ö
Update rate: Write on power-up
