Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menus 15 to 17
SM-I/O 24V
Unidrive SP Advanced User Guide 319
Issue Number: 10 www.controltechniques.com
On Unidrive SP the menu for the relevant slot appears for the new Solutions Module category with the default parameter values for the new category.
When no Solutions Module is installed in the relevant slot this parameter is zero. When a Solutions Module is installed this parameter displays the
identification code.
205: SM-I/O 24V Protected
The new parameter values are not stored in the drive EEPROM until the user performs a parameter save by setting Pr xx.00 to 1000 (or 1001 in the
case of solely using the 24V back-up power supply) and pressing the stop/reset button. When parameters are saved by the user in the drive
EEPROM, the option code of the currently installed Solutions Module is saved in the drive EEPROM. If the drive is subsequently powered-up with a
different Solutions Module installed, or no Solutions Module is installed when one was previously installed, the drive will trip on SLx.dF or SLx.nF.
This module contains two processors, and thus two software versions. Pr x.02 shows the version number of the main module processor. Pr x.51,
which is normally used to give a sub-version number, shows the software version in the slave processor.
These parameters indicate the input and output states of the terminals.
Setting these parameters to On(1) causes the input sense to the destination parameter to be inverted or the output sense from the source to be
inverted.
x.01
Solutions Module ID code
RO Uni PT US
Ú
0 to 599
Ö
Update rate: Write on power-up
x.02 Solutions Module main software version
RO Uni NC PT
Ú
00.00 to 99.99
Ö
Update rate: Write on power-up
x.03 T5 digital I/O 3 state
x.04 T6 digital I/O 4 state
x.05 T7 digital input 5 state
x.06
T8 digital input 6 state
x.07 T9 digital input 7 state
x.08 Relay 1 state
x.09 T3 digital I/O 1 state
x.10 T4 digital I/O 2 state
RO Bit NC PT
Ú
OFF (0) or On (1)
Ö
Update rate: 4ms write
x.11 T3 digital I/O 1 invert
x.12 T4 digital I/O 2 invert
x.13 T5 digital I/O 3 invert
x.14 T6 digital I/O 4 invert
x.15 T7 digital input 5 invert
x.16 T8 digital input 6 invert
x.17 T9 digital input 7 invert
x.18 Relay 1 invert
RW Bit US
Ú
OFF (0) or On (1)
Ö
OFF (0)
Update rate: 4ms read
