This parameter sets the output mode for terminals 10 and 12 as follows:
This parameter indicates the states of relay 2. This parameter can only have the values of 0.0% or 100.0%. 0.0% indicates relay open and 100%
indicates relay closed.
Setting this parameters to On(1) causes the output sense from the source to be inverted.
Source parameter defines the parameter to be represented by the relay 2 output terminal.
This parameter can be used to scale the analog output if so desired.
The parameter required to be represented as an analog signal by the analog output on terminal 12, should be programmed into this parameter.
The parameter required to be represented as an analog signal by the analog output on terminal 10, should be programmed into this parameter.
This parameter can be used to scale the analog output if so desired.
x.39 Analog output mode
RW Uni US
Ú
0-20, 20-0, 4-20, 20-4
Ö
0-20
Update rate: Background read
Parameter value Parameter string Mode
0 0-20 0-20mA
1 20-0 20-0mA
2 4-20 4-20mA
3 20-4 20-4mA
x.40 Relay 2 state
RO Uni NC PT
Ú
0.0 or 100.0%
Ö
Update rate: 4ms write
x.42 Relay 2 invert
RW Bit US
Ú
OFF (0) or On (1)
Ö
OFF (0)
Update rate: 4ms read
x.43 Relay 2 source
RW Uni DE US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on drive reset
x.45 Analog output 2 scaling
RW Uni US
Ú
0.000 to 4.000
Ö
1.000
Update rate: Background read
x.47 Analog output 2 source
RW Uni US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on reset
x.48 Analog output 1 source
RW Uni US
Ú
Pr 0.00 to Pr 21.51
Ö
Pr 0.00
Update rate: Read on reset
x.49 Analog output 1 scaling
RW Uni US
Ú
0.000 to 4.000
Ö
1.000
Update rate: Background read
