Menus 15 to 17
SM-Applicat’ns
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
330 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
Defines the baud-rate (or bits-per-second) for the on-board EIA-RS485 port. The following are supported:
Note that this parameter is not relevant when the EIA-RS485 port mode is set to 25 (CTSync Master) or 26 (CTSync Slave).
Defines a fixed delay between receiving a message on the EIA-RS485 port and the response being transmitted. This can be useful in 2-wire
configurations where it takes a finite time for the master (host) to switch from transmit mode to receive mode. There is always at least a 1ms delay
and this parameter can be used to extend it.
This parameter allows a 1ms delay to be introduced between the Applications module enabling the EIA-RS485 transmitter and actually commencing
the transmission. This should only be required if it is found that the recipient of the transmission is receiving a corrupted start of message.
This parameter is available on SM-Applications Lite module but is not allowed to be set to a 1 (On). Controls where the output of the DPL PRINT
command is sent. If set to zero (Off), the output is sent to the programming client (SyPTPro) and if set to 1 (On) it will be sent to the EIA-RS485 port.
Defines the scheduling period (tick-time), in milliseconds, for the DPL CLOCK task. A value of zero will disable the CLOCK task.
Prior to version 01.05.00 Unidrive SP the default for this parameter was 0ms (disabled).
Defines the scheduling rate for the POS tasks to suit the application performance and the resource needed to run the user DPL program. The
following values are defined::
Set this parameter in order for the user DPL program to automatically run at power-on/reset. If this is changed and the new setting needs to be used
on power-up ensure that a drive parameter save is performed.
x.07 EIA-RS485 Baud Rate
♣♥
Access
RW
Range 0-9 (300-
115200bps)
Default 4 (4800) Update Rate Initialisation
Display Value Description
300 0 300bps
600 1 600bps
1200 2 1200bps
2400 3 2400bps
4800 4 4800bps
9600 5 9600bps
19200 6 19200bps
38400 7 38400bps
57600 8 57600bps
115200 9 115200bps
x.08 EIA-RS485 Turn-around Delay
♣♥
Access RW Range 0 to 255ms
Default 2ms Update Rate Initialisation
x.09 EIA-RS485 Tx Enable Delay
♣♥
Access RW Range 0 to 1ms
Default 0ms Update Rate Initialisation
x.10 DPL Print Routing
♦♣♥
Access
RW
Range
0
♦♣♥
/1
♣♥
Default 0 Update Rate Initialisation
x.11 Clock Task Scheduling (ms)
♦♣♥
Access RW Range 0 to 200ms
Default 10ms Update Rate Initialisation
x.12 POS task scheduling rate
♦♣♥
Access RW Range 0 to 6
Default 0 Update Rate Initialisation
Display Value Description
diSAbled 0 Disabled
0.25 1 250µs
0.5 2 500µs
131ms
242ms
454ms
868ms
