Emerson unidrive sp User Manual

Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menus 15 to 17
SM-Applicat’ns
Unidrive SP Advanced User Guide 329
Issue Number: 10 www.controltechniques.com
.
Defines the mode of operation (or protocol) for the on-board EIA-RS485 port. For details of these modes, refer to the Applications Modules User
Guide..
x.06 EIA-RS485 Mode
♣♥
Access RW Range 0 to 255
Default 1 Update Rate Initialisation
Table 5.37 Serial modes - parameter Pr x.06
Mode Description
1
4-wire CT-ANSI Slave
The port is set to 1 start bit, 7 data bits, even parity and 1 stop bit.
2 Reserved
3 Reserved
4 Reserved
5
2-wire CT-ANSI Slave
The port is set to 1 start bit, 7 data bits, even parity and 1 stop bit.
6 User mode. 1 start bit, 7 data bits, EVEN parity, 1 stop bit (10 bits total)
7 User mode. 1 start bit, 8 data bits, EVEN parity, 1 stop bit (11 bits total)
8 User mode. 1 start bit, 8 data bits, NO parity, 1 stop bit (10 bits total)
9 Reserved
10 Reserved
11 Reserved
12 Reserved
13,43,73
4-wire Modbus RTU slave
The EIA-RS485 port is set for:
Mode 13: 1 start bit, 8 data bits, NO parity, 2 stop bits.
Mode 43: 1 start bit, 8 data bits, EVEN parity, 1 stop bit.
Mode 73: 1 start bit, 8 data bits, ODD parity, 1 stop bit.
14, 44, 74
4-wire Modbus ASCII slave
The EIA-RS485 is set for:
Mode 14: 1 start bit, 7 data bits, NO parity, 2 stop bits
Mode 44: 1 start bit, 7 data bits, EVEN parity, 1 stop bit
Mode 74: 1 start bit, 7 data bits, ODD parity, 1 stop bit
15, 45, 75
2-wire Modbus RTU slave
The EIA-RS485 port is set for:
Mode 15: 1 start bit, 8 data bits, NO parity, 2 stop bits.
Mode 45: 1 start bit, 8 data bits, EVEN parity, 1 stop bit.
Mode 75: 1 start bit, 8 data bits, ODD parity, 1 stop bit.
16, 46, 76
2-wire Modbus ASCII slave
The EIA-RS485 is set for:
Mode 16: 1 start bit, 7 data bits, NO parity, 2 stop bits
Mode 46: 1 start bit, 7 data bits, EVEN parity, 1 stop bit
Mode 76: 1 start bit, 7 data bits, ODD parity, 1 stop bit
17, 47, 77
4-wire Modbus RTU master
The EIA-RS485 port is set for:
Mode 17: 1 start bit, 8 data bits, NO parity, 2 stop bits.
Mode 47: 1 start bit, 8 data bits, EVEN parity, 1 stop bit.
Mode 77: 1 start bit, 8 data bits, ODD parity, 1 stop bit.
18, 48, 78
4-wire Modbus ASCII master
The EIA-RS485 is set for:
Mode 18: 1 start bit, 7 data bits, NO parity, 2 stop bits
Mode 48: 1 start bit, 7 data bits, EVEN parity, 1 stop bit
Mode 78: 1 start bit, 7 data bits, ODD parity, 1 stop bit
19, 49, 79
2-wire Modbus RTU master
The EIA-RS485 port is set for:
Mode 19: 1 start bit, 8 data bits, NO parity, 2 stop bits.
Mode 49: 1 start bit, 8 data bits, EVEN parity, 1 stop bit.
Mode 79: 1 start bit, 8 data bits, ODD parity, 1 stop bit.
20, 50, 80
2-wire Modbus ASCII master
The EIA-RS485 is set for:
Mode 18: 1 start bit, 7 data bits, NO parity, 2 stop bits
Mode 48: 1 start bit, 7 data bits, EVEN parity, 1 stop bit
Mode 78: 1 start bit, 7 data bits, ODD parity, 1 stop bit
25
Applications CT-Sync Master
The baud rate is fixed at 896875bps
26
Applications CT-Sync Slave
The baud rate is fixed at 896875bps

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
