Emerson unidrive sp User Manual

Menu 21
Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
360 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
Pr 21.12 shows the stator resistance of the motor. The units vary with the drive size to ensure that the full range of likely resistances can be
represented with suitable resolution. The table below shows the units. Therefore 1.000 in the parameter represents the resistance shown in the units
column.
s
21.09 Rated voltage
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range Open-loop, Closed-loop vector, Servo 0 to AC_VOLTAGE_SET_MAX V
Default Open-loop, Closed-loop vector, Servo
200V rating drive: 230V
400V rating drive: EUR: 400V, USA: 460V
575V rating drive: 575V
690V rating drive: 690V
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.09
Update rate Level 4 read
21.10 Rated power factor
Drive modes Open-loop, Closed-loop vector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
31 111
Range Open-loop, Closed-loop vector 0.000 to 1.000
Default Open-loop, Closed-loop vector 0.850
Normal
parameter
Open-loop, Closed-loop vector Pr 5.10
Update rate Background read
21.11 Number of motor poles
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range Open-loop, Closed-loop vector, Servo 0 to 60 (Auto to 120 POLE)
Default
Open-loop, Closed-loop vector
Servo
0 (Auto)
3 (6 POLE)
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.11
Update rate Background read
21.12 Stator resistance
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
31 111
Range Open-loop, Closed-loop vector, Servo 0.000 to 65.000
Default Open-loop, Closed-loop vector, Servo 0.000
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.17
Update rate Background read
Drive size
Units
Ω
SP0xxx 10.0
SP1xxx to SP5xxx 1.0
SP6xxx to SP9xxx and SPMxxxxx 0.01

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
