Parameter
structure
Keypad and
display
Parameter
x.00
Parameter
description format
Advanced parameter
descriptions
Macros
Serial comms
protocol
Electronic
nameplate
Performance RFC mode
Menu 21
Unidrive SP Advanced User Guide 361
Issue Number: 10 www.controltechniques.com
Pr 21.15 does not have an equivalent normal motor parameter, but shows when motor 2 is active.
21.13 Voltage offset
Drive modes Open-loop
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 111
Range Open-loop 0.0 to 25.0 V
Default Open-loop 0.0
Normal
parameter
Open-loop Pr 5.23
Update rate Background read
21.14
Transient inductance (σL
s
)
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
31 111
Range Open-loop, Closed-loop vector, Servo 0.000 to 500.000 mH
Default Open-loop, Closed-loop vector, Servo 0.000
Normal
parameter
Open-loop, Closed-loop vector, Servo Pr 5.24
Update rate Background read
21.15 Motor 2 active
Drive modes Open-loop, Closed-loop vector, Servo
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Default Open-loop, Closed-loop vector, Servo 1
Normal motor
parameter
Open-loop, Closed-loop vector, Servo Pr 21.15
Update rate Background write
21.16 Thermal time constant
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
1111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0.0 to 3000.0
Default
Open-loop,
Closed-loop vector,
Servo
Regen
89.0
20.0
89.0
Normal motor
parameter
Open-loop, Closed-loop vector, Servo,
Regen
Pr 4.15
Update rate Background read
