364 Unidrive SP Advanced User Guide
www.controltechniques.com Issue Number: 10
21.25 Motor saturation breakpoint 1
Drive modes Closed-loop vector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Closed-loop vector 0 to 100% of rated flux
Default Closed-loop vector 50
Normal
parameter
Closed-loop vector Pr 5.29
Update rate Background read
21.26 Motor saturation breakpoint 2
Drive modes Closed-loop vector
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
111
Range Closed-loop vector 0 to 100% of rated flux
Default Closed-loop vector 75
Normal
parameter
Closed-loop vector Pr 5.30
Update rate Background read
21.27 Motoring current limit
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range
Open-loop, Closed-loop vector, Servo,
Regen
0 to MOTOR2_CURRENT_LIMIT_MAX %
Default
Open-loop
Closed-loop vector, Servo, Regen
165.0*
175.0*
Normal
parameter
Open-loop, Closed-loop vector, Servo,
Regen
Pr 4.05
Update rate Background read
21.28 Regen current limit
Drive modes Open-loop, Closed-loop vector, Servo, Regen
Coding
Bit SP FI DE Txt VM DP ND RA NC NV PT US RW BU PS
11 1 111
Range Open-loop, Closed-loop vector, Servo 0 to MOTOR2_CURRENT_LIMIT_MAX %
Default
Open-loop
Closed-loop vector, Servo, Regen
165.0*
175.0*
Normal
parameter
Open-loop, Closed-loop vector, Servo,
Regen
Pr 4.06
Update rate Background read

Emerson unidrive sp Specifications

General

Type	AC Drive
Storage Temperature	-40°C to +70°C
Communication Options	CANopen, Ethernet, Profibus, DeviceNet
Safety Features	Safe Torque Off (STO), Safe Stop 1 (SS1), Safe Operating Stop (SOS)
Overload	150% for 60 seconds
Enclosure	IP20
Output Voltage Range	0 - Input Voltage
Protection Features	Overcurrent, Overvoltage, Undervoltage, Short Circuit
Humidity	95% non-condensing
Cooling Method	Fan cooled
Dimensions	Varies depending on the power rating and enclosure type
Weight	Varies depending on the power rating and enclosure type
Input Voltage	200 VAC - 690 VAC ±10%
