Commissioning Proline Prowirl F 200 PROFIBUS PA
108 Endress+Hauser
Configuring the frequency output
Navigation
"Setup" menu → Advanced setup → Pulse/frequency/switch output
Structure of the wizard for the frequency output
Measuring value at minimum frequency
Invert output signal
Maximum frequency value
Measuring value at maximum frequency
Failure mode
Assign frequency
output
Minimum frequency value
Mass flow
Steam qualityTemperature
Volume flow
Flow velocity
Total mass
flow
Calculated saturat.
steam pressure
Corrected
volume flow
Energy flow
Heat flow
difference
Off
Actual value
Defined value
0 Hz
Failure
frequency
End of wizard
Operating mode
Operating mode
Frequency
Volume flow unit
Temperature unit
Mass flow unit
Energy flow unit
Corrected volume
flow unit
Pressure unit
Mass flow unit
Energy flow unit
Velocity unit
A0020789-EN
 27 "Pulse/frequency/switch output" wizard in the "Advanced setup" submenu: "Operating mode"
parameter"Frequency" option
