Proline Prowirl F 200 PROFIBUS PA Commissioning
Endress+Hauser 109
Parameter overview with brief description
Parameter Prerequisite Description Selection / User
entry
Factory setting
Operating mode – Define the output as a pulse,
frequency or switch output.
• Pulse
• Frequency
• Switch
Pulse
Assign frequency output The Frequency option is
selected in the Operating
mode parameter (→  106).
Select process variable for
frequency output.
• Off
• Volume flow
• Corrected volume
flow
• Mass flow
• Flow velocity
• Temperature
• Calculated
saturated steam
pressure
*
• Steam quality
*
• Total mass flow
*
• Energy flow
*
• Heat flow
difference
*
Off
Mass flow unit – Select mass flow unit.
Effect
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Unit choose list Country-specific:
• kg/h
• lb/min
Volume flow unit – Select volume flow unit.
Effect
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Unit choose list Country-specific:
• m³/h
• ft³/min
Corrected volume flow unit – Select corrected volume flow
unit.
Effect
The selected unit applies for:
Corrected volume flow
Unit choose list Country-specific:
• Nm³/h
• Sft³/h
Energy flow unit For the following order code:
"Sensor version", option "Mass
flow"
Select energy flow unit.
Result
The selected unit applies for:
• Outputs
• Low flow cut off
Unit choose list Country-specific:
• kW
• Btu/h
Pressure unit For the following order code:
"Sensor version", option "Mass
flow"
Select process pressure unit.
Effect
The unit is taken from the:
• Calculated saturated steam
pressure
• Atmospheric pressure
• Maximum value
• Fixed process pressure
• Pressure
• Reference pressure
Unit choose list Country-specific:
• bar
• psi
Velocity unit – Select velocity unit.
Result
The selected unit applies for:
• Flow velocity
• Maximum value
Unit choose list Country-specific:
• m/s
• ft/s
