Proline Prowirl F 200 PROFIBUS PA Commissioning
Endress+Hauser 113
Operating mode
Operating mode
Limit
Status
Assign limit
Assign status
Switch
Switch output
function
Switch-on value
Switch-off value
Switch-on delay
Switch-off delay
Failure mode
Inverted output signal
Ende of wizard
Steam
quality
Low flow cut
off
Volume
flow unit
Mass flow
unit
Corrected
vol. flow
Flow
velocity
Temp.
Calc. sat.
steam press.
Corr. vol.
flow unit
Velocity
unit
Energy
flow unit
Energy
flow
Total mass
flow
Mass flow
unit
Reynolds
number
Unit
totalizer
Mass flow
Volume
flow
Heat flow
difference
Totalizer
1/2/3
Temp.
unit
Pressure
unit
Energy
flow unit
Energy
flow unit
A0020794-EN
 29 "Pulse/frequency/switch output" wizard in the "Advanced setup" submenu: "Operating mode"
parameter"Switch" option (part 2)
Parameter overview with brief description
Parameter Prerequisite Description Selection / User
entry
Factory setting
Operating mode – Define the output as a pulse,
frequency or switch output.
• Pulse
• Frequency
• Switch
Pulse
Switch output function The Switch option is selected
in the Operating mode
parameter.
Select function for switch
output.
• Off
• On
• Diagnostic
behavior
• Limit
• Status
Off
