Commissioning Proline Prowirl F 200 PROFIBUS PA
114 Endress+Hauser
Parameter Prerequisite Description Selection / User
entry
Factory setting
Assign diagnostic behavior • The Switch option is
selected in the Operating
mode parameter.
• The Diagnostic behavior
option is selected in the
Switch output function
parameter.
Select diagnostic behavior for
switch output.
• Alarm
• Alarm or warning
• Warning
Alarm
Assign limit • The Switch option is
selected in the Operating
mode parameter.
• The Limit option is selected
in the Switch output
function parameter.
Select process variable for limit
function.
• Volume flow
• Corrected volume
flow
• Mass flow
• Flow velocity
• Temperature
• Calculated
saturated steam
pressure
*
• Steam quality
*
• Total mass flow
*
• Energy flow
*
• Heat flow
difference
*
• Reynolds number
*
• Totalizer 1
• Totalizer 2
• Totalizer 3
Volume flow
Assign flow direction check • The Switch option is
selected in the Operating
mode parameter.
• The Flow direction check
option is selected in the
Switch output function
parameter.
Select process variable for flow
direction monitoring.
• Off
• Volume flow
• Mass flow
• Corrected volume
flow
Volume flow
Assign status • The Switch option is
selected in the Operating
mode parameter.
• The Status option is
selected in the Switch
output function parameter.
Select device status for switch
output.
• Low flow cut off
• Digital output 2
Low flow cut off
Mass flow unit – Select mass flow unit.
Effect
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Unit choose list Country-specific:
• kg/h
• lb/min
Volume flow unit – Select volume flow unit.
Effect
The selected unit applies for:
• Output
• Low flow cut off
• Simulation process variable
Unit choose list Country-specific:
• m³/h
• ft³/min
Corrected volume flow unit – Select corrected volume flow
unit.
Effect
The selected unit applies for:
Corrected volume flow
Unit choose list Country-specific:
• Nm³/h
• Sft³/h
Energy flow unit For the following order code:
"Sensor version", option "Mass
flow"
Select energy flow unit.
Result
The selected unit applies for:
• Outputs
• Low flow cut off
Unit choose list Country-specific:
• kW
• Btu/h
