GLOBAL SETTING / GENERAL / MONITORING / CONTACT WEAR / Time Delay
Range
0.00 ~ 1.00 sec
Default
1.0
Step
0.1 sec
Set time delay when switch (or CB) contact wear reaches set value.
GLOBAL SETTING / GENERAL / MONITORING / CONTACT WEAR / Interrupt I1
Range
1.00~600.00 kA
Default
1
Step
0.01 kA
To set operation number of the curve for interruption current to
operation number at the point 1(maximum operation number).
GLOBAL SETTING / GENERAL / MONITORING / CONTACT WEAR / Interrpt Ct1
Range
1~60000
Default
10000
Step
0.01kA
To set interruption current of the curve for interruption current to
operation number at the point 2(maximum operation number).
GLOBAL SETTING / GENERAL / MONITORING / CONTACT WEAR / Interrupt I2
Range
1.00~600.00 kA
Default
20.00
Step
0.01kA
To set operation number of the curve for interruption current to
operation number at the point 2(minimum operation number).
GLOBAL SETTING / GENERAL / MONITORING / CONTACT WEAR / Interrpt Ct 2
Range
1~60000
Default
16
Step
1
To set operation number of the curve for interruption current to
operation number at the point 2(minimum operation number).
[CONTACT WEAR]
>Function: DISABLE
>Alarm Pickup: 20.0
>Time Delay: 0.01
Interrupt I1: 1.00
Interrpt Ct1: 10000
[0.00~600.00:0.01s]
[CONTACT WEAR]
>Function: DISABLE
>Alarm Pickup: 20.0
>Time Delay: 0.01
>Interrupt I1: 1.00
Interrpt Ct1: 10000
[1.00~600.00:0.01kA]
[CONTACT WEAR]
>Function: DISABLE
>Alarm Pickup: 20.0
>Time Delay: 0.01
>Interrupt I1: 1.00
>Interrpt Ct1: 10000
[1~60000:1]
[CONTACT WEAR]
>Interrupt I2: 20.0
>Interrpt Ct2: 16
>A Wear Set: 100.00
>B Wear Set: 100.00
>C Wear Set: 100.00
[1.00~600.00:0.01kA]
[CONTACT WEAR]
>Interrupt I2: 20.0
>Interrpt Ct2: 16
A Wear Set: 100.00
B Wear Set: 100.00
C Wear Set: 100.00
[1~20000:1]
