COMMUNICATION/ EVENT&ETC / AI ‘V’ Unit
Range
1V, 10V
Default
10V
Step
~
Set the data format of AI(Analog Input) points associated with a
voltage.
1V: 1V per 1count of transmitted data. If a voltage magnitude is
13.2kV, the corresponding AI point transmits 13200.
10V: 10V per 1count of transmitted data. If a voltage magnitude is
13.2kV, the corresponding AI point transmits 1320.
NOTE :
These settings are supported from version 6.04 of
EVRC2A_N6,NT. The data format of AI points associated with a
voltage on previous version is fixed to support 10V per 1count .
COMMUNICATION/ EVENT&ETC / AI ‘P’ Unit
Range
1K, 10K
Default
10K
Step
~
Set the data format of AI(Analog Input) points associated with a
power.
1K: 1K per 1count of transmitted data. If active power is 660kW, the
corresponding AI point transmits 660.
10K: 10K per 1count of transmitted data. If active power is 660kW, the
corresponding AI point transmits 66.
NOTE :
These settings are supported from version 6.04 of
EVRC2A_N6,NT. The data format of AI points associated with a
voltage on previous version is fixed to support 10K per 1count .
[EVENT&ETC]
> CI Evt Mode: ALL
> AI ‘V’ Unit: 10V
> AI ‘P’ Unit: 10K
[EVENT&ETC]
> CI Evt Mode: ALL
> AI ‘V’ Unit: 10V
> AI ‘P’ Unit: 10K
