Mounting the Switch
2-8 Installation
3. PlugthepowercordfromthepowersupplyintotheswitchDCpowerreceptaclethatis
appropriateforyourtype ofpowersupply.
•FortheD2‐PWRsupply,plugintothePWR1‐AorPWR2‐Areceptacle.
•FortheD2‐PWR‐POEsupply,plugintothePWR1‐BorPWR2‐Breceptacle.
4. Chooseoneofthefollowing:
•Ifyouaredoneinstallingpowersupplies,proceedto“MountingtheAssembledKitIntoa
Rack”onpage 2‐9.
•Ifyouneedtoinstalloneormoreadditionalpowersupplies,either
‐ RepeatthisEdgeofTrayInstallationprocedure,or
‐ ProceedtotheMiddleofTray
Installationprocedureonpage2‐8.
5. (Optional)Usethewiretiesprovidedtosecurethepowercordsinsidetherackmountingtray.
Middle of Tray Installation
Usingoneofthehook&loopstrapsprovided,secureapowersupplytooneofthemiddle
mountingpositionsontherackmountkitasfollows:
1. Threadthestrapthroughthemountingtrayandaroundonesideofthepowersupplyinthe
followingorder:
a. Throughthebridgeanchoron
onesideofthepowersupply
b. Under thepowersupply
c. Throughthebridgeanchorontheothersideofthepowersupply
d. Wraptheendsofthestrapoverthetopofthepowersupplyandfastensecurely
2. RepeatStep 1withanotherhook&loopstraptosecuretheothersideofthe
powersupplyto
themountingtray.FinalplacementisshowninFigure 2‐8onpage 2‐9.
3. PlugthepowercordfromthepowersupplyintotheswitchDCpowerreceptaclethatis
appropriateforyourtype ofpowersupply.
•FortheD2‐PWRsupply,plugintothePWR1‐AorPWR2‐
Areceptacle.
•FortheD2‐PWR‐POEsupply,plugintothePWR1‐BorPWR2‐Breceptacle.
4. Chooseoneofthefollowing:
•Ifyouaredoneinstallingpowersupplies,proceedto“MountingtheAssembledKitIntoa
Rack”onpage 2‐9.
•Ifyouneedtoinstalloneormoreadditionalpowersupplies,
either
‐ RepeatthisMiddleofTrayInstallationprocedure,or
‐ RepeattheEdgeofTrayInstalla tion procedureonpage2‐6.
5. (Optional)Usethewiretiesprovidedtosecurethepowercordsinsidetherackmountingtray.
Note: When installing power supplies in the middle of the rack mount tray, you do not need to use
the mounting holes on the edge of the tray. Instead, you will use the available bridge anchors in a
staggered fashion as show in Figure 2-8 on page 2-9.
