Enterasys D2G124-12 User Manual

Mounting the Switch
2-12 Installation
a. Withthehookandloopsidesattachedtogether,peelbacktheadhesivecoveringonone
sideofeachhook&loopfastenerandapplytooppositecornersonthebottomofthe
D2‐HIPWR‐POE.
b. Oncethehook&loopfastenersareadheredtothebottomoftheD2‐HIPWR‐POE,remove

theadhesivecoveringontheothersideofbothhook&loopfastenersandadheretothe
tablemountingtray.
c. FirmlypresstheD2‐HIPWR‐POEagainstthetablemounttrayandholdtogetherforafew
seconds.
8. PlugtheDCpowercordfromthepowersupplyintotheswitchDC
powerreceptaclethatis
appropriateforyourtype ofpowersupply.
•FortheD2‐PWRsupply,plugintothePWR1‐AorPWR2‐Areceptacleontheswitch.
•FortheD2‐PWR‐POEsupply,plugintothePWR1‐BorPWR2‐Breceptacleontheswitch.
•FortheD2‐HIPWR‐POE,see
“ConnectingaD2‐HIPWR‐POEPowerCombiner”on
page 2‐25.
9. PlugtheACcordintothepowersupply’sACreceptacle.
10. (Optional)Usethewiretiesprovidedtosecurethepowercordsinsidethetablemounting
tray.
11. Usingappropriatescrewsandthefourscrewholesinthecorneredgesofthe
tablemounting
tray,attachtheassembledkitunderneathyourdesiredtablelocation.Mounttheassembled
unitinplacebypositioningthescrewholesoveryourinstalledtablescrewsandpulling
slightlyforwardontheunit.
12. Attachnetworkcables.Referto“ConnectingtotheNetwork”onpage 2‐28formore
information.
13. Plug
eachACpowercordintoadedicated,groundedACoutlet.See“ConnectingPowerto
theSwitch”onpage 2‐26forinformationonredundancyandtheinitializationprocess.
Installing the Switch on a Wall
Toinstalltheswitchinthewallmountkitandtheninstallitonawall,refertoFigure 2‐11on
page 2‐13andproceedasfollows:
Note: Once assembled, the serial number on the bottom of your D2 switch will be visible through
the window on the bottom of the table mount kit.
Caution: The wall location and wall mounting screws/anchoring method that the installer selects for
mounting the D2 switch must be capable of supporting 55 lbs (25kg).
Advertencia: La ubicación de la pared y el método de anclaje o los tornillos de montaje de la pared
que el instalador seleccione para montar el interruptor D2 deberán ser capaces de soportar un peso
de 55 lbs (25 kg).
