D2-HIPWR-POE Specifications
A-2 Specifications
D2-HIPWR-POE Specifications
Table A‐2providesthespecificationsfortheD2‐HIPWR‐POEpowercombiner.
Physical
Dimensions 4.06 H x 20.9 W x 21.5 D (cm)
1.6 H x 8.25 W x 8.5 D (in.)
Approximate Weight (without
power supply)
• D2G124-12 - 3.65 lb/1.66 kg
• D2G124-12P - 4.02 lb/1.82 kg
Predicted hours for Mean Time
Between Failures (MTBF)
Information about MTBF is located at
http://www.enterasys.com/support/mtbf.
Heat Dissipation (maximum) Same as Power Consumption (below)
AC Power Requirements
Input Voltage 100 to 240 VAC
Power Consumption • D2G124-12 - 30 W
• D2G124-12P - 130W
Input Frequency 50-60Hz
Input Current • D2G124-12 - 2.0A
• D2G124-12P - 3.2A
Thermal Output • D2G124-12 - 110V - 0.3A / 102.39 (BTUs/hr)
• D2G124-12P - 110V - 2.16A / 443.69 (BTUs/hr)
Environmental
Operating Temperature • D2G124-12 - 0°C to 60°C (32°F to 140°F)
• D2G124-12P - 0°C to 50°C (32°F to 122°F)
Storage Temperature -40°C to 70°C (-40°F to 158°F)
Operating Relative Humidity 5% to 95%
Table A-1 D2 Specifications (continued)
Item Specification
Table A-2 D2-HIPWR-POE Specifications
Item Specification
D2-HIPWR-POE
Size 80.6 L x 90.0 W x 32.9 H mm (3.17 L x 3.54 W x 1.3 H in)
Input Voltage: Accepts two 50V 2.6A (max) power supplies
Tripping Point 5A
