Connecting Power to the Switch
2-26 Installation
2. ConnectthefourprongendoftheconnectingcordtotheD2HIPWRPOE’sPowerOutput
receptacle.
3. Repeatsteps1and2ifyouareconnectingasecondD2HIPWRPOEforredundancy.
4. ConnectthethreeprongendoftheconnectingcordtothePWR1Bpowerinputreceptacleof
theD2G124
12P.IfconnectingasecondD2HIPWRPOEforredundancy,connectittothe
PWR2Bpowerinput.
5. ProceedtoconnectpowertotheswitchasdescribedinConnectingPowertotheSwitch.
Connecting Power to the Switch
Youcanconnecttoasingleprimarysourceofpowerortotwosourcesofpowerforredundancy,as
describedinthefollowingsections.Theexampleusedheredescribesconnectingtwopower
sources.
ThefollowingredundantpowersuppliesareavailabletobepurchasedfromEnterasysfor
connectiontotheD2switch.
Followtheappropriateinstructionsinthissectiontoinstallyour
component(s):
•D2PWR,aDCpowersupplycapableofprovidingpowertoafullyloadednonPoEswitch.
•D2PWRPOE,aDCpowersupplyrecommendedforPoEpowerredundancy
ToconnectpowertotheD2switch:
1. Ifyouhavenotalready
donesoaspartofoneoftheswitchmountingprocedures,plugtheDC
endofthepowercordfromeachpowersupplyintoeachoftheswitchDCpowerreceptacles
thatareappropriateforyourtypeofpowersupplies.
•FortheD2PWRsupply,plugintothePWR1Aand
PWR2Areceptacles
•FortheD2PWRPOEsupply,plugintothePWR1BandPWR2Breceptacles
•FortheD2HIPWRPOEpowercombiner,attachcablingasinstructedinConnectinga
D2HIPWRPOEPowerCombineronpage 225.
2. PlugtheACcordintothepowersupply’sACreceptacle.Repeat
foreachpowersupply.
3. PlugeachACpowercordintoadedicated,groundedACoutlet.
4. VerifythattheappropriatepowerLEDs(PWR1andPWR2)turnonasdescribedinTable 21
onpage 227andtheCPU(system)LEDturnsreduntiltheD2completesitsinitialization.
TheseLEDsarevisiblefrom
thebackoftheswitchasshowninFigure 11onpage 12,aswell
asfromthetopandfrontoftheswitchasshowninFigure 12onpage 12.
Iftheinitializationprocessissuccessful,theCPULEDturnsgreen.IftheCPULEDdoesnotturn
green,
refertoChapter 3fortroubleshootinginformation.
Notes: Both power supplies must be of the same type to support redundancy.
The D2-PWR supply will power either the D2G124-12 or the D2G124-12P without PoE support. The
D2-PWR-POE is the only supply for powering the D2G124-12P with PoE support
Note: To take advantage of redundancy capabilities, each power cord must be plugged into a
separate, dedicated AC outlet.
Note: It is normal for the surface of the device to be warm.
