Mounting the Switch
Enterasys D-Series Hardware Installation Guide 2-15
8. PlugtheDCpowercordfromthepowersupplyintotheswitchDCpowerreceptaclethatis
appropriateforyourtype ofpowersupply.
•FortheD2‐PWRsupply,plugintothePWR1‐AorPWR2‐Areceptacle.
•FortheD2‐PWR‐POEsupply,plugintothePWR1‐BorPWR2‐B
receptacle.
•FortheD2‐HIPWR‐POEpowercombiner,see“ConnectingaD2‐HIPWR‐POEPower
Combiner”onpage 2‐25.
9. PlugtheACcordintothepowersupply’sACreceptacle.
10. (Optional)Usethewiretiesprovidedtosecurethepowercordsinsidethewallmountingtray.
11. Usingappropriatescrewsandthescrew
holesineachcorneredgeofthewallmountingtray,
attachtheassembledkittoyourdesiredwalllocation.Securetheassembledunitinplaceby
positioningthescrewholesovertheinstalledwallscrewsandpullingslightlydownwardon
theunit.
12. Attachnetworkcables.Referto“ConnectingtotheNetwork
”onpage 2‐28formore
information.
13. PlugeachACpowercordintoadedicated,groundedACoutlet.See“ConnectingPowerto
theSwitch”onpage 2‐26forinformationonredundancyandtheinitializationprocess.
14. (Optional)Ifyouhavepurchasedanoptionalplasticcover,attachittothemountedD2switch
asdescribedin“InstallingtheOptionalPlasticCover”(page 2‐33).
Installing the Switch in the Lockbox and Mounting on a Wall
ToassembletheswitchandothercomponentsintheD2lockbox,proceedasdescribedinthe
followingsections:
• InstallingtheSwitchintheLockbox
•Installyourpowersupplies,followingthestepsineither“InstallingPowerSupplies”
(page 2‐16)or“InstallingtheD2‐HIPWR‐POEintheLockbox”(page 2‐18)
•“
ConnectingNetworkCablingandAttachingtheWireReliefBracket”(page 2‐21)
•“MountingtheLockboxontheWall”(page 2‐22)
•“AttachingandLockingtheCover”(page 2‐23)
•“RemovingtheLockboxCover”(page 2‐25)
Installing the Switch in the Lockbox
Toinstalltheswitchinthelockboxtray,proceedasfollows:
1. Detachthelockboxkeyandplaceitinasecurelocationforlateruse.
Note: Once assembled, the serial number on the bottom of your D2 switch will be accessible
through the window on the bottom of the wall mounting tray. In the event you need to view it, you will
need to detach the wall mounting tray from the wall and (if installed) remove the power supply from
underneath the serial number window.
