Mounting the Switch
Enterasys D-Series Hardware Installation Guide 2-25
Removing the Lockbox Cover
RemovethelockboxcovertoaccesstheD2switchasfollows:
1. Unlockthelockusingyourprovidedkey.
2. Slidethelatchonthelockassemblytotheunlockedposition.
3. Removethethreecoverscrews.
4. Unhookthecoverfromthemountingtabsandremovethecover.
Connecting a D2-HIPWR-POE Power Combiner
YoucanconnectasingleD2‐HIPWR‐POEpowercombinertoyourD2G124‐12Pswitchortwo
D2‐HIPWR‐POEpowercombinersforredundancytoprovidemaximum(15.4watts)PoEpower
onalltwelvefrontpanelRJ45ports.UseFigure 2‐23asareferenceforthefollowingprocedure.
Figure 2-23 D2-HIPWR-POE Cable Connections
Toconnecta
D2‐HIPWR‐POEtotheD2G124‐12Pswitch:
1. ConnecttheDCpowercordfromeachD2‐PWR‐POEpowersupplytoeachofthePowerIn
receptaclesontheD2‐HIPWR‐POE.
Note: Only D2-PWR-POE power supplies can be combined using the D2-HIPWR-POE combiner,
D2-PWR power supplies cannot be combined.
1 D2G124-12P Switch 4 D2-PWR-POE Power Supplies
2 D2-HIPWR-POE Power Combiner 5 Connecting Cord
3 AC Power Cords
Note: The D2-HIPWR-POE will not supply power to the D2 switch until both input power supplies
are connected to the D2-HIPWR-POE.
