Console Port Pinout Assignments
Enterasys D-Series Hardware Installation Guide A-7
MGBIC-LC09 Specifications (1000BASE-LX)
Console Port Pinout Assignments
Referbackto“ConnectingtotheConsolePort”onpage 2‐27forinformationaboutconsoleport
pinoutassignments.
Regulatory Compliance
Thisproductmeetsthesafety,electromagneticcompatibility(EMC),andenvironmental
requirementslistedinTable A‐19:
Table A-17 MGBIC-LC09 Optical Specifications
Item 62.5 µm MMF 50 µm MMF 10 µm SMF
Transmit Power (minimum) -11.5 dBm -11.5 dBm -9.5 dBm
Receive Sensitivity -20 dBm -20 dBm -20 dBm
Link Power Budget 8.5 dBm 8.5 dBm 10.5 dBm
Table A-18 MGBIC-LC09 Operating Range
Item Modal Bandwidth @ 1300 nm Range
62.5 µm MMF 500 MHz/km 2-550 Meters
50 µm MMF 400 MHz/km 2-550 Meters
50 µm MMF 500 MHz/km 2-550 Meters
10 µm SMF N/A 2-10,000 Meters
Table A-19 Compliance Standards
Regulatory Compliance Standard
Safety UL 60950-1, FDA 21 CFR 1040.10 and 1040.11, CAN/CSA C22.2
No. 60950-1, EN 60950-1, EN 60825-1, EN 60825-2,
IEC 60950-1, 2006/95/EC (Low Voltage Directive)
Electromagnetic Compatibility (EMC) FCC 47 CFR Part 15 (Class A), ICES-003 (Class A), EN 55022
(Class A), EN 55024, EN 61000-3-2, EN 61000-3-3, AS/NZ
CISPR-22 (Class A). VCCI V-3. CNS 13438 (BSMI), 2004/108/EC
(EMC Directive)
Environmental 2002/95/EC (RoHS Directive), 2002/96/EC (WEEE Directive),
Ministry of Information Order #39 (China RoHS)
