1-Gigabit Ethernet and 100Base-FX Transceiver (SFP) Specifications
A-4 Specifications
1-Gigabit Ethernet and 100Base-FX Transceiver (SFP)
Specifications
TheD2SFP(Mini‐GBIC)portinterfaceslotssupport1‐Gbpsfiber‐opticandcopperconnectionsas
describedinTable A‐5.TheseoptionalMini‐GBICsarehotswappable.
ThespecificationsfortheMini‐GBICsshowninTable A‐6throughTable A‐18meetorexceedthe
IEEE802.3z‐1998standard.
MGBIC-LC01/MGBIC-MT01 Specifications (1000BASE-SX)
Table A-5 Mini-GBIC Input/Output Port Specifications
Item Specification
MGBIC-LC01 1 LC fiber-optic multimode port that is compliant with the 1000BASE-SX
standard and has an LC connector.
MGBIC-MT01 1 MT-RJ fiber-optic multi-mode port that is compliant with the 1000BASE-SX
standard and has an MT-RJ connector.
MGBIC-02 1 RJ45 copper connection that is compliant with the 1000BASE-T standard
and has an RJ45 connector.
MGBIC-LC03 1 LC fiber-optic multimode port that is compliant with the 1000BASE-SX
standard and has an LC duplex style connector.
MGBIC-LC04 1 LC fiber-optic multimode port that is compliant with the 100BASE-FX
standard and has an LC connector.
MGBIC-LC05 1 LC fiber-optic single-mode port that is compliant with the 100BASE-FX
standard and has an LC connector.
MGBIC-LC07 1 LC fiber-optic single-mode port that is compliant with the 1000BASE-ELX
standard and has an LC connector.
MGBIC-08 1 LC fiber-optic single-mode port that is compliant with the 1000BASE-ELX
standard and has an LC connector.
MGBIC-LC09 1 LC fiber-optic single-mode port that is compliant with the 1000BASE-LX
standard and has an LC connector.
Table A-6 MGBIC-LC01/MGBIC-MT01 Optical Specifications
Item 62.5 µm MMF 50 µm MMF
Transmit Power (minimum) -9.5 dBm -9.5 dBm
Receive Sensitivity -17 dBm -17 dBm
Link Power Budget 7.5 dBm 7.5 dBm
Table A-7 MGBIC-LC01/MGBIC-MT01 Operating Range
Item Modal Bandwidth @ 850 nm Range
62.5 µm MMF 160 MHz/km 2-220 Meters
62.5 µm MMF 200 MHz/km 2-275 Meters
50 µm MMF 400 MHz/km 2-500 Meters
50 µm MMF 500 MHz/km 2-550 Meters
