Mounting the Switch
Enterasys D-Series Hardware Installation Guide 2-11
2. Mounttheswitchinthecenterofthetablemountingtra y,aligningthethreescrewholeson
thebottomoftheswitchwiththethreeholesinthetablemountingtray.
3. Usingthethreescrewsprovided,fastentheswitchtothetablemountingtray.
4. Usingoneofthehook&loopstraps
provided,completethefollowingstepstosecureoneend
ofthepowersupplyinthepositionshown:
a. Threadthestrapthroughthemountingtrayandaroundthepowersupplyinthe
followingorder:
(1) Throughthebridgeanchorbesidethepowersupply
(2) Underthepowersupply
(3) Outthroughthefirstmountinghole(closest
tothetopofthepowersupply)
(4) Inthroughthesecondmountinghole
b. Wraptheendsofthestrapoverthetopofthepowersupplyandfastensecurely.
5. RepeatStep 4tosecuretheotherendofthepowersupplytothemountingtray.
6. (Optional)RepeatStep 4tosecureasecondpower
supplytothemountingtray.
7. (Optional)IfyouareinstallingaD2‐HIPWR‐POE,refertoFigure 2 ‐10andproceedasfollows:
Figure 2-10 Attaching the D2-HIPWR-POE to the Table Mounting Tray
1 D2-PWR-POE power supply 3 Hook & loop fasteners with adhesive
2 D2G124-12P switch 4 D2-HIPWR-POE power combiner
