Power Supply Specifications
Enterasys D-Series Hardware Installation Guide A-3
Power Supply Specifications
Table A‐3providesthespecificationsfortheavailableD2powersupplies:
Torque Values
Thefollowingtabledescribestherecommendedtorquevaluestousewheninstalli ngtheD2
switchusingstandardthreadedfastenermachinescrewsandbolts.
Table A-3 Power Supply Specifications
Item Specification
D2-PWR
Input Frequency 50 to 60 Hz
Input Voltage/Current: 100 - 240Vac / 2.0A
Output Voltage 19V 6.32A
D2-PWR-POE
Input Frequency
47 to 63 Hz
Input Voltage/Current 100 - 240Vac / 3.2A
Output Voltage 50V 2.6 A max
Table A-4 Recommended Torque Values by Screw Size
Screw Size Torque in Pounds Bit Size
English Metric -%5 Nominal +%5
N/A N/A 1.42 1.5 1.57 0
2 – 56 1.5 2.85 3.0 3.15 0
4 – 40 2.5 4.75 5.0 5.25 0/1
6 – 32 3.5 8.55 9.0 9.45 1
8 – 32 4.5 17.10 18.0 18.90 2
10 – 32 5 30.40 32.0 33.60 2
1/4 – 20 6.5 63.65 67.0 70.35 3
