Maintenance
Eppendorf Xplorer
®
/Eppendorf Xplorer
®
plus
English (EN)
7.5.3.5 Removing and installing 1 200 μL channels
Only disassemble the channels when the upper part is detached from the lower part.
1 Housing case
2 Piston actuator
3 Inner part
4 Piston rod in the guiding rail of the
piston actuator
5 Channel, consisting of a piston, a
cylinder and a tip cone
6 Fixing strip
7 Base plate
8 Unlocking tool for 1 200 µL lower part
1
2
3
4
5
6
7
8
