C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-117 Rev.1
Apply grease at the location shown in the figure.
SK-1A: 26 g
CAUTION
If grease is on the areas shown in the figure, wipe off the grease.
3
9
11
8
9
10
7
5
4
1
3
2
6
Installing the Reduction Gear
