C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-144 Rev.1
Remove the Motor Plate.
6
S01: 2-M4x10
A
Motor Plate
1
2
3
4
5
6
Motor Unit Disassembly
