C8-B/C12-B Service Manual Maintenance Information Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 1-18 Rev.1
Inject grease from the grease nipple using a grease gun.
SK-1A: 6 g (C8L), 12 g (C8XL, C12XL)
Remove the grease nipple from the Joint #2 grease inlet.
Attach the grease plug to the Joint #2 grease inlet.
POINT
If the grease plug is damaged or deteriorated, replace it with a new one.
3
Grease Gun
4
5
