C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-199 Rev.1
Remove the Arm2 side cover (both sides).
Removing the Cable unit.
Perform step  through 12 of step .
Removing the J4 Timing Belt.
Perform steps  and .
Remove the Arm4 unit.
1. Pull out all cables passing through the Arm4 extension part from the Arm4 unit side.
8
9
10
11
Arm4 unit
Removing the Arm4 Unit
7
8
10
9
5
9
9
9
11
6
5
8
9
4
