C8-B/C12-B Service Manual Maintenance Information Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 1-20 Rev.1
Attach the grease plug to the Joint #3 grease inlet.
POINT
If the grease plug is damaged or deteriorated, replace it with a new one.
Joint #4 Reduction Gear Unit
Remove the grease plug from the Joint #4 grease inlet of the Arm #4.
5
1
