C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-249 Rev.1
3. Disconnect the J5 Motor Connectors (CN151, CN351, CN451, CN460).
4. Remove the J6 Motor unit.
Perform steps  to .
5. Disconnect the Ground Wires (FB14, FB15, FB17) from the cable protection plate.
S04: 3-M4x6
A
FB14
FB15
FB17
Removing the Cable Unit
