Epson C8-B - Page 310

C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-268 Rev.1
11. Connect the Ground Wires (PE9, PE10, FB13).
12. Bind the following connector cables using the wire tie (AB200).
CN341, CN592, CN522, CN521, CN203, LED, CN441, CN440
Wire tie
S04: 3-M4x6
（0.9 +/- 0.1 N·m）
A
PE9
PE13
PE10
Installing the Cable Unit
