C8-B/C12-B Service Manual Maintenance Disclosure Scope: Maintenance Trained Personnel Only
(C) Seiko Epson Corporation 2-292 Rev.1
Remove the gyro board 1 protective plate.
4
A
Gyro board 1 protective plate
Gyro board 1
Gyro board 1 fixing plate
Gyro board 1 protective plate
Gyro board 1
Gyro board 1 fixing plate
S03: 1-M3x20
with washer
4
3
2
Removing Gyro Board 1
