SC-F2000 Revision C
DISASSEMBLY & ASSEMBLY Disassembly and Assembly Procedure 78
Confidential
3. Disengage the two hooks, and remove the REAR COVER SUB ASSY.
Figure 3-21. Removing the REAR COVER SUB ASSY (2)
Hook
Hook
REAR COVER
SUB ASSY
