Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series Revision I
Stylus Photo R2000/R2000s Adjustment 193
8.4.3 Required Adjustments
The table below lists the required adjustments depending upon the parts being repaired or replaced. Find the part(s) you removed or replaced, and check which
adjustment(s) must be carried out. About the First dot position adjustment, it's included in the PW adjustment.
Table 8-17. Required Adjustment List
Priority
1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23
PF Belt tension adjustment
Pf Roller Shaft Center
Support position adjustment
ASF Guide Roller LDs
Position adjustment
PG adjustment
Mist Recovery check
EEPROM Data Copy
Initial setting / USB ID Input
Head ID Input
Consumables maintenance
counter
Ink charge
Initialize PF deterioration
offset
Disenable PF deterioration
offset
Initialize front tray
print counter
Disable front tray
print counter
PW adjustment
Head angular adjustment
Multi Sensor Adjustment
(Ink Mark Sensor adjustment)
Bi-D adjustment
PF adjustment
CR motor heat protection
control
PF motor heat protection
control
Colorimetric calibration
Final check pattern print
ASF Assy
Remove
--- --- *1 --- --- --- --- --- --- --- --- --- --- --- O --- --- --- --- --- --- --- O
Replace
--- --- O --- --- --- --- --- --- --- --- --- --- --- O --- --- --- --- --- --- --- O
CR Motor
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O --- --- O
Printhead
Remove
--- --- --- O --- --- --- --- --- --- --- --- --- --- O O --- O --- --- --- --- O
Replace
--- --- --- O --- --- --- O --- O --- --- --- --- O O --- O --- --- --- O O
Main Board
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Replace
(Read OK)
--- --- --- --- --- O --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O O
Replace
(Read NG)
--- --- --- --- --- --- O O *1 --- --- O --- O O O O O O O O O O
PS Board
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O O O O
High Voltage
Module
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Replace
--- --- --- --- O --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Front Paper Guide/
Paper Eject Roller
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- O --- --- --- O --- --- --- O
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- O --- --- --- O --- --- --- O
PF Roller Shaft
Remove
O O --- O --- --- --- --- --- --- --- --- --- --- O --- --- --- O --- --- --- O
Replace
O O --- O --- --- --- --- --- --- --- --- O --- O --- --- --- O --- --- --- O
PF Motor
Remove
O O --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O --- --- --- O
Replace
O O --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O --- O --- O
Waste Ink Pad/
Front Paper Guide
Pad
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- O
Replace
--- --- --- --- --- --- --- --- O --- --- --- --- --- --- --- --- --- --- --- --- --- O
Adjustment
Item
Part Name

Epson Stylus Photo R2000 Series Specifications

General

Print Technology	Inkjet
Max Print Resolution	5760 x 1440 optimized dpi
Number of Ink Colors	8
Borderless Printing	Yes
Operating Systems	Windows, Mac OS
Ink Type	UltraChrome Hi-Gloss 2
Ink Colors	Cyan, Magenta, Yellow, Red, Orange, Matte Black, Photo Black, Gloss Optimizer
Ink Droplet Size	1.5 picoliters
Connectivity	USB, Ethernet, Wi-Fi
Media Sizes Supported	4" x 6", 5" x 7", 8" x 10", 11" x 14", 13" x 19"
Media Types Supported	Plain paper, photo paper, fine art paper, canvas
Interface	USB, Ethernet
