Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series Revision I
SC-P400 Series Adjustment 215
9.5.3 Required Adjustments
The table below lists the required adjustments depending upon the parts being repaired or replaced. Find the part(s) you removed or replaced, and check which
adjustment(s) must be carried out. About the first dot position adjustment, it's included in the PW adjustment.
Table 9-8. Required adjustment list
PF belt tension adjustment
ASF guide roller LDs
position adjustment
PF Roller Shaft Center
Support position adjustment
F/W update
EEPROM data copy
Initial setting
Mist recovery check
PG adjustment (Mecha adj.)
Head ID input
Ink charge
Initialize front tray print counter
Initialize PF deterioration offset
CR encoder check
PF encoder check
APG check
Waste ink pad counter
Disable front tray print counter
Disable PF deterioration offset
PW adjustment
Head angular adjustment
Bi-d adjustment
PF/EJ adjustment
CR motor heat protection control
PF motor heat protection control
Colorimetric calibration
Final check pattern print
Factory settings
Main board
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 2
Replace
(Read OK)
--- --- --- 1 2 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 3 4
Replace
(Read NG)
--- --- --- 1 --- 2 --- --- 3 --- --- --- --- --- --- 4 5 6 7 8 9 10 11 12 13 14 15
PS board
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 2
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 2 3 4 5
CR motor
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 2
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- 2 3
High voltage
module
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 2
Replace
--- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- --- 2 3
Printhead
Remove
--- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- 2 3 4 --- --- --- --- 5 6
Replace
--- --- --- 1 --- --- --- 2 3 4 --- --- --- --- --- --- --- --- 5 6 7 --- --- --- 8 9 10
CR scale
Remove
--- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- --- --- 2 3
Replace
--- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- --- --- 2 3
APG assy
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- 2 3
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- 2 3
PF encoder
Remove
--- --- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- --- 2 3
Replace
--- --- --- --- --- --- --- --- --- --- --- --- --- 1 --- --- --- --- --- --- --- --- --- --- --- 2 3

Epson Stylus Photo R2000 Series Specifications

General

Print Technology	Inkjet
Max Print Resolution	5760 x 1440 optimized dpi
Number of Ink Colors	8
Borderless Printing	Yes
Operating Systems	Windows, Mac OS
Ink Type	UltraChrome Hi-Gloss 2
Ink Colors	Cyan, Magenta, Yellow, Red, Orange, Matte Black, Photo Black, Gloss Optimizer
Ink Droplet Size	1.5 picoliters
Connectivity	USB, Ethernet, Wi-Fi
Media Sizes Supported	4" x 6", 5" x 7", 8" x 10", 11" x 14", 13" x 19"
Media Types Supported	Plain paper, photo paper, fine art paper, canvas
Interface	USB, Ethernet
