Epson Stylus Photo R2000 Series User Manual

Stylus Photo R1900/R2880/R2000/R2000s/SC-P400 Series Revision I
SC-P400 Series Disassembly 208
9.4.2 Procedure of Disassembly
The flowchart below lists the step-by-step disassembly procedures.
Rear Housing
(p.79)
Start
Front Decoration
Plate Left/Right
(p.79)
Panel Unit
(p.188)
Paper Support Assy
(p.78)
Decoration Plate
Left/Right (p.82)
Cover Open Sensor
(p.138)
Upper Housing /
Printer Cover (p.83)
Upper Housing
Support Assy (p.85)
Lower Housing /
Printer Mechanism
(p.98)
Board assy (Main
board / Power supply
board) (p.210)
High Voltage
Module (p.89)
LED Board
(p.88)
APG Assy
(p.91)
CR Scale
(p.92)
CR Motor
(p.131)
PF Encoder
(p.134)
Printhead / CSIC
Assy (p.94)
Paper EJ Frame
Assy / Front Cover
/ CDR Tray Base
(p.114)
CDR Release
Lever Sub Assy
(p.116)
Ink System Unit
(p.118)
CDR Sensor
(p.136)
Front Paper Guide /
Paper EJ Roller / Front
Paper Guide Pad Tray
(p.121)
PF Encoder
(p.134)
Upper Paper Guide
Assys (p.129)
PF Roller Shaft
(p.124)
CR Encoder
(p.134)
Carriage Shaft /
Carriage Unit (p.100)
APG Assy
(p.91)
LED Board
(p.88)
CR Scale
(p.92)
Upper Paper Guide
Assys (p.129)
PE Sensor Holder
(p.137)
FLAG Release
Assy (p.128)
Release Holder
Assy (p.127)
PictBridge Holder
Assy (p.113)
ASF Assy
(p.108)
PE Sensor Holder
(p.137)
ASF Motor
(p.133)
PF Motor
(p.132)
Waste Ink Pad / Waste
Ink Tube Left/Right
(p.112)
Front Paper Guide
Pad (p.111)
Foot (p.113)
Stacker Assy
(p.78)
C H E C K
P O I N T
 The boxes shown in a dotted-line are not the shortest
procedures, but are necessary to proceed to the next step.
 Since a prototype was used to illustrate these disassembly
and assembly procedures, the appearance of some parts
may differ from those on an actual product.
 This section describes the parts of red frame only. For
other parts, please refer to the procedure of Stylus Photo
R1900/R2880/R2000/R2000s.
Panel FFC Cover
(p.187)
Wireless LAN Board
Assy (p.209)
Panel FFC Cover
(p.187)
Front Decoration
Plate Left/Right
(p.79)
Panel Unit
(p.188)
PW sensor (p.135)

Epson Stylus Photo R2000 Series Specifications

General

Print Technology	Inkjet
Max Print Resolution	5760 x 1440 optimized dpi
Number of Ink Colors	8
Borderless Printing	Yes
Operating Systems	Windows, Mac OS
Ink Type	UltraChrome Hi-Gloss 2
Ink Colors	Cyan, Magenta, Yellow, Red, Orange, Matte Black, Photo Black, Gloss Optimizer
Ink Droplet Size	1.5 picoliters
Connectivity	USB, Ethernet, Wi-Fi
Media Sizes Supported	4" x 6", 5" x 7", 8" x 10", 11" x 14", 13" x 19"
Media Types Supported	Plain paper, photo paper, fine art paper, canvas
Interface	USB, Ethernet
