16
7.3 Log on Page
7.3.1 Image
The following figure shows the layout of the logon page.
Figure 7-1 Log on Page
7.3.2 Input Items
Table 7-3 Input Items
7.3.3 Button
Table 7-4 Button
The Administrator logon page is displayed in the following cases.
User authentication link clicked
Direct access to a page that requires logging on
Web Config accessed 20 min. or longer since the previous time
Accessing Web Config while currently logged on as an administrator in another web browser
Text box for entering the current password. The
entered value is masked with '*'.
If the Enter key is pressed while the cursor is in this
text box, the same process as when the OK button is
"Note: It is recommended to
communicate via HTTPS for
entering an administrator
Button for logging on. After the user logs on, the Product Status page on
the Status tab is displayed.
