10.3.1.2 Confirm Page
10.3.1.2.1 Image
Figure 10-7 Confirm Page
10.3.1.2.2 Input Information
Table 10-20 Input Information
10.3.1.2.3 Button
There is a button to proceed to the remaining settings based on the values entered on this page, and a button to go back to the
previous page.
Table 10-21 Button
"Confirm the following settings."
This message is shown at the top of the page, followed by the
setting items and their values.
"Communication will be shut down temporarily to
enable the new settings. You cannot access the
network immediately after the settings are changed."
This message is shown at the bottom of the page.
This button is used to apply the entered values to the system
shown on the Confirm Wi-Fi/Network Settings page. If pressed,
Web Config goes to the Result page.
This button is used to go back to the Wi-Fi/Network Settings page.
Input Information
Button
To Next Page
