63
10.3.3.2.2 Input Information
Table 10-37 Input Information
10.3.3.2.3 Button
There is a button to proceed to the remaining settings based on the values entered on this page, and a button to go back to the
previous page.
Table 10-38 Button
10.3.3.3 Result page
The following figure shows the page that is displayed after the network settings are processed. The content of the Result page will
vary based on the result (success or failure).
10.3.3.3.1 Image
Figure 10-16 Result page
10.3.3.3.2 Setting Result
Table 10-39 Setting Result
"Confirm the following settings."
This message is shown at the top of the page, followed by the setting
items and their values.
"Communication will be shut down temporarily
to enable the new settings. You cannot access
the network immediately after the settings are
This message is shown at the bottom of the page.
This button is used to apply the entered values to the system shown
on the Confirm Wired LAN Settings page. If pressed, Web Config goes
This button is used to go back to the Wired LAN Settings page.
"Restarting communication may take a few
minutes."
"If you want to change the settings, close the
Web Config and check your IP address. Then
enter your IP address in the browser to restart the
This message is shown if setup is successful.
This message is shown if Wi-Fi/Network setup fails.
Setting Result
