21
9.2 Log on Page
9.2.1 Image
The following figure shows the layout of a log on page.
Figure 9-1 Log on Page
9.2.2 Input Items
Table 9-2 Input Items
9.2.3 Button
Table 9-3 Button
Administrator logon page is shown in the following cases.
When the user authentication link is clicked.
Direct access to the page which requires logging on.
Web Config access after 20 min. from last access.
During administrator logon, Web Config access after administrator logon from other web browser.
A text box to the input current password. The input
value is masked with '*'.
Pressing the Enter key with the cursor in this text box
performs the same processing as when pressing the
OK button.
When ' ' is pressed, the input value is displayed.
When ' ' is pressed, the input value is masked with
"Note: It is recommended to
communicate via HTTPS for
entering an administrator
Button for logging on. After logging on, the top page of each function is
displayed.
