10.6.1.3 Import
The Import page consists of a Top page, Category Select page, Confirmation page, and Result page.
10.6.1.3.1 Top Page
10.6.1.3.1.1 Image
When “Import” is chosen in the menu frame, the top page is displayed as shown below.
Figure 10-64 Top Page
10.6.1.3.1.2 Comment
The following table shows the comments.
Table 10-167 Comment
Items
Description
Condition
"Select a file for import and enter
a password assigned for export. "
Displayed at the top of the page.
-
"Sending file. Please wait…"
Displayed above the next button.
Displayed after the next button is
pressed.
10.6.1.3.1.3 Setting Items
The following table shows the layout of this settings area.
Table 10-168 Setting Items

Items
Description
"File"
The user can enter the import file. Use the file button to select a file.
"Password"
Use the text box to set a password for file decryption.
0 – 20 bytes in characters. (ASCII 0x20 – 0x7E)
The values are masked.
Comment
Setting Items
Button
