Epson TM-P20II

75
10.4.2.2 Import Page
The page is shown after the ‘Import’ button is pressed.
The following figure shows the layout of the page for importing the CA certificate into the printer.
10.4.2.2.1 Image
Figure 10-24 Import Page
10.4.2.2.2 Setting Items
Table 10-56 Setting Items
10.4.2.2.3 Note
The following table shows the note on the CA Certificate Import page.
Table 10-57 Note
10.4.2.2.4 Button
Table 10-58 Button
10.4.2.2.5 Error Pop-up Window
Table 10-59 Error Pop-up Window
Items
Description
"CA Certificate"
-Enter the file of the CA certificate to import it into the
printer. You can also use the file button to select the file.
Items
Description
"Note: It is recommended to communicate via HTTPS for
importing a certificate."
Fixed Strings
Items
Description
"OK"
-Button at the bottom of the main frame to perform
importing.
After the "Import" button is pressed, Web Config displays
one of the following pages depending on the result.
- If importing is successful, the top page is shown in the
main frame.
- If importing fails, the result page is shown in the main
frame.
- If the entered value is invalid, a pop-up window is shown.
"Back"
Button at the bottom of the main frame for going back to
the top page of the CA Certificate settings.
Items
Description
"Select a CA Certificate."
This message is shown when the file of the CA Certificate is
not selected.
Setting Items
Button
Note
