Epson TM-P20II

60
When the “Apply” button is pressed, Web Config displays a pop-up window that shows the following message if it recognizes an
error in the entered value.
Table 10-30 Error Pop-up
10.3.2.4 Confirm Wi-Fi Setup Page
10.3.2.4.1 Image
Figure 10-12 Confirm Wi-Fi Setup Page
10.3.2.4.2 Display Items
Table 10-31 Display Items
“Security Level” is determined by the values on the Wi-Fi Setting page.
Table 10-32 Value for Security Level
Items
Description
"Invalid value below."
This message is shown when the value entered for SSID, Password,
or Confirm Password is invalid. The item names of the invalid
values are shown under the message in the left cell. If there are two
or more items whose values were invalid, those items are listed line
by line.
"Passwords you entered do not match."
This message is shown if the values entered for Password and
Confirm Password do not agree.
Items
Description
"Confirm the following settings."
This message is shown at the top of the page.
"SSID"
The value entered on the Wi-Fi Setup page is shown.
"Communication Mode"
The value entered on the Wi-Fi Setup page is shown.
"Security Level"
The value entered on the Wi-Fi Setup page is shown.
"Communication will be shut down temporarily to
enable the new settings. You cannot access the
network immediately after the settings are changed."
This message is shown at the bottom of the page.
the values of Wi-Fi Setting page
Security Level of Confirm
Wi-Fi Setup Page
SSID
Security Level of selected SSID
Length of Security Level
- Select "Enter SSID".
-
0
"None"
5
"WEP-64bit(40bit)"
Others
"Unknown"
- Select from list.
- "Unknown"
0
"None"
10 (hexdecimal)
"WEP-64bit(40bit)"
26 (hexdecimal)
"WEP-128bit(104bit)"
5 (not hexdecimal)
"WEP-64bit(40bit)"
13 (not hexdecimals)
"WEP-128bit(104bit)"
Others
"Unknown"
- Others
-
- Select Security Level
Display Items
Button
