Chapter C: System functions ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
Caution: This command must be used with the utmost prudence, since movement speed is very high.
Although the STE command is not an alias, the syntax STE.1+=1000 or STE.1-=1000 are allowed, in order to
make relative jump movements, because an absolute jump movement can be dangerous if the motor is far
away from the position to reach.
Examples:
STE.1+=1000 ;Relative jump movement. the motor realizes a jump movement of 1000 increments
in the positive direction.
STE.1=1000 ;Absolute jump movement. The motor makes a jump movement from its actual
position to the position of 1000 increments.
13.3.9 BRK and STP commands
The BRK command (BRaKe) stops a movement with the deceleration programmed in parameter K206. It is
also used with infinite rotary movement (refer to §13.3.3
).
The STP command (SToP) behaves the same way as BRK but the deceleration is infinite. The braking is then
very sudden. This command is to be used only in case of emergency.
Caution: The sudden deceleration set with the STP command can damage the mechanical parts of the
system.
Note: BRK and STP commands do not stop the sequence; thus, the movements defined in a sequence
will be executed.
13.3.10 Parameters defining units scales
Parameter K50 defines the unit scale movements:
Parameter K50:
The POS, SPD and ACC commands are used respectively to determine a position to reach, a speed or an
acceleration. The arguments of these commands must be given in a unit called user increment. The
Command format [s] <p1> Comment Units
STE.<axis>[s] = <p1>
Sign + or -
or nothing
-2
31
to (2
31
-1)
Performs a step movement of the length contained in <p1>
[upi]
[rupi]
Available on DSC2P DSC2V DSCDP DSCDL DSCDM
Command format Comment
BRK.<axis>
Stops the movement using the deceleration programmed in parameter K206 but it does not stop the sequence.
Stops an infinite rotary movement.
STP.<axis> Stops the movement using an infinite deceleration but it does not stop the sequence.
Available on DSC2P DSC2V DSCDP DSCDL DSCDM
K Name Comment
K50
Set point
calculator shift
Enables the diminution of the cinematic quantities values. 1dpi = 2
K50
* 1upi
Depth 0 for primary encoder and depth 1 for secondary encoder (depth 1 is ONLY available on DSC2P
and DSC2V)
