Chapter C: System functions ETEL Doc. - Operation & Software Manual # DSC2P 903 / Ver. F / 3/6/05
Remark: The (binary) value of parameter 2 is masked by parameter K184. Refer to §13.9.4 for more
information.
• For Action = 3 and 4
’Parameter 2’ is a bits field defining ’Status Drive’ SD2 (alias of monitoring M61) and monitoring M63 (TEB
status). The bits# 0 to 15, set to 1 in ’Parameter 2’, correspond to the bits of SD2 and monitoring M63 to be set
to 1 and bits# 16 to 31, set to 1 in ’Parameter 2’, correspond to the bits of SD2 and monitoring M63 to be set to 0.
Example:
The user wants to clear bit# 10 of SD2 while setting bits# 8 and 9 of monitoring M63:
Remark: The (binary) value of parameter 2 is masked by parameter K184. Refer to §13.9.4
for more
information.
13.9.5 Masks, actions selection
The values defined in ’Parameter 1’ (digital outputs DOUTs or XDOUTs) and ’Parameter 2’ (’Status Drive’ SD2)
are masked with parameters K184 or K185 (TMK, Trigger MasK, alias command). This means the actions
defined in the triggers are selected (active/inactive) with those parameters. The bits set to 1 are allowed to be
modified by the trigger. Refer to §13.11
for more information about ’Status Drive’ (SD2) and monitoring M63.
Remark: TMK alias use the same syntax than parameter K185. Refer to §6.3
for more information about
the syntax and the possible operators.
For example, these masks may be used to 'protect' some DOUTs from being modified by triggers, when they
are used by another function (refer to §13.4
for more information).
Remark: Parameter K184 may also be set with bits 0 - 15 of monitoring M63.
Action = 3
Comment
No change No change No change No change No change No change
Clear bit# 10
No change No change No change
Set bit# 9 Set bit# 8
No change No change No change No change No change No change No change No change
Bit # of SD2 - 15 14 13 12 11 10 9 8 - - - 15 14 13 12 11 10 9 8
Bit # of M63 31-242322212019 18 171615-109 8 76543210
Parameter 2
value
0 0 0 0 0 0 262144 0 0 0 512 256 0 0 0 00000
K Alias Name Bit Comment
K183 -
Trigger mask:
DSO-HIO digital outputs
0 - 7 Selection of XDOUTs (on DSO-HIO optional board) modified by the trigger
K184 -
Trigger mask:
’Status Drive’ bits:
monitorings M61 and M63
0 - 7
or
0 - 15
Selection of bits 8 to 15 of SD2 (’Status Drive’, alias M61) modified by the trigger
or
Selection of bits 0 to 15 of monitoring M63 modified by the trigger
K185 TMK
Trigger mask: DSC2P / DSC2V
digital outputs
0 - 3 Selection of DOUTs modified by the trigger
Trigger mask: DSCDP / DSCDL
digital outputs
0 - 1 Selection of DOUTs modified by the trigger
Trigger mask: DSCDM
digital outputs
0 - 2 Selection of DOUTs modified by the trigger
